| Frame | 6061-T6 Heat Treated Alloy PTC Disc Frame w/ Integrated Headtube, Internal Cable Routing, Smooth Welding & Haro 3D Dropouts w/ Integrated Chain Tensioners. 21.75" top tube. |
|---|---|
| Fork | Full chromoly 1 1/8" Threadless Steerer w/ Tapered Legs |
| Colors | Blue |
| DRIVETRAIN | |
| Cranks | 2-pc Forged Alloy w/ 24mm Hollow Spindle - 175mm - 44t Alloy Chainring |
| Bottom Bracket | Press-Fit BB86, Sealed Bearing |
| Sprocket | 40t Alloy Chainring |
| Gearing | 40/16 |
| Pedals | Alloy DX, 9/16" |
| Chain | KMC Z33 1/2 X 3/32" |
| Cassette | 16t Cassette |
| WHEELS | |
| Tires | Kenda Konversion 24 X 1.95 front, 24 X 1.75" rear. |
| Front Hub | 36h Alloy Sealed-Bearing |
| Rear Hub | 36h sealed disc 16T cassette rear |
| Rims | 24" Alloy 36h, Double Wall |
| BRAKING SYSTEM | |
| Brake | Promax DSK-300 Mechanical Disc Brake w/ 160mm Rotor |
| Brake Lever | Promax XL-373 Two Finger |
| OTHER COMPONENTS | |
| Grips | Micro-Knurl Grip |
| Handlebar | Haro full chromoly, 5.25" Rise |
| Stem | Forged Alloy Top-Load, 45mm reach |
| Headset | 1-1/8"" Sealed Threadless |
| Seat | Haro Slim Plastic Pivotal |
| Seat Post | Alloy Pivotal, 27.2mm |
| Seat Post Clamp | Alloy, 31.8mm |
